Gauge Glass Pair Valve



Gauge Glass Pair Valve widely used in various industries to visually monitor the liquid level in tanks or vessel. The compact design of gauge glass cock valves enables it to be safely located close to the tank or vessel.

JDM Gauge Glass Pair Valve are machined from Solid Round Bar Stock Needle type design with vent & drain arrangement & available in Screwed (BSP/NPT) Connection.

Product Features:

  • Economical valve for regulating pressure up to 5000 PSI
  • Suitable for air, water, oil, gas and other fluids
  • Available in Round and Square body design
  • Robust construction
  • Excellent durability

Technical Specifications:

Type Square body
Body / Bonnet/ Stem MOC S.S. Bar Stock 202, 304, 316
Seal Packing Viton* O-ring and Teflon* backup ring
Actuation Manual
Wheel / Handle Bakelite / Zinc Plated steel
End Screwed, Flanged
Rating Class 125, 150
Design Standard Mfg. Standard
Size 15MM to 50MM
*Registered trademark of DuPont
