Steam Trap



Steam traps are a type of automatic valve that filters out condensate (i.e. condensed steam) and non-condensable gases such as air without letting steam escape. In industry, steam is used regularly for heating or as a driving force for mechanical power.

We supplies the high and robust quality Thermodynamic type Steam Trap for your application. The thermodynamic trap is an extremely robust steam trap with a simple mode of operation. The trap operates by means of the dynamic effect of flash steam as it passes through the trap. The only moving part is the disc above the flat face inside the control chamber or cap.

Product Features:

  • Robust and Compact in size
  • Inbuilt Strainer that avoids the Clogging
  • Hardened Disc To Withstand Continuous Water Hammering
  • Seat Integral with Body

Technical Specifications:

Type Thermodynamic
Body MOC Cast Stainless Steel (ASTM A 351 GR. CF 8/ CF 8M)
Forged Steel
Plug / Disc S.S. CF 8 / CF8M
Screen S.S. 304
Actuation Automatic
End Screwed, Socket Weld
Design Standard Mfg. Standard
Size 15MM to 25MM
