A sight glass is a device which allows a person to see the level of fluids or gases in a system, or to look inside a closed system to see what is happening inside. Glass tubes which allow for internal views are sometimes referred to as viewing glasses. Sight glasses are used on many different types of equipment and they add to the safety and ease of operation. Like other equipment parts, a sight glass is replaceable if it becomes damaged or compromised in some way
Annu Valve Products Sight Glasses are constructed using a robust tie rod cage and heavy wall borosilicate glass. Their design offers a 360 degree viewing area and they are available with both carbon and stainless steel flanges either unlined or PFA lined for corrosive duties.
| Type | Sight Flow Indicator |
|---|---|
| Body and Pillar Rod MOC | Carbon Steel Stainless Steel S.S 304 , 304L, 316, 316L |
| Gasket | S.S. 304L |
| Glass | Tempered Borosilicate Glass |
| Fastener | Carbon Steel Stainless Steel S.S 304 , 304L, 316, 316L |
| Rating | Class 125, 150 |
| Design Standard | Mfg. Standard |
| Size | 40MM to 150MM |
